Specification Product Suspended Solids (Sludge Concentration/ TSS/ MLSS) meter Model SUP-ADT3300 Main materials lower casing: Aluminum with powder covering cover: PA66+GF25+FR Waterproof rate IP65 Sto
Range: 0.1 ~ 20000 mg/L; 0.1 ~ 45000 mg/L; 0.1 ~ 120000 mg/L
Resolution: Less than ± 5% of the measured value
Pressure range: ≤0.4MPa
Power supply: AC220V±10%; 50Hz/60Hz
Specification
| Product | Suspended Solids (Sludge Concentration/ TSS/ MLSS) meter |
| Model | SUP-ADT3300 |
| Main materials | lower casing: Aluminum with powder covering |
| cover: PA66+GF25+FR | |
| Waterproof rate | IP65 |
| Storage temperature | -20~70℃ |
| Operation Temperature | -15~60℃ |
| Output | three-way analog output 4-20mA, response parameters and corresponding scope can be programmed Note: the maximum load is 500 ohms |
| Relay | three-way relay can be set up, and response parameters and response values can be programmed |
| Display | 128 * 64 dot matrix LCD with LED backlight |
| Digital Communication | MODBUS RS485 communication function, which can transmit real-time measurements |
| Power Supply | AC：85-500V, 50/60HZ, 5W DC:9-36V |
| Size | 145*125*162mm L*W*H |
| Weight | 1.35 KG |
Introduction
SUP-ADT3300 suspended solids meter, based on the infrared absorption scattered light method and combined with the application of ISO7027 method, can guarantee the continuous and accurate detection of turbidity. Based on ISO7027, infrared double scattering light technology will not be affected by chroma for the measurement of turbidity value. According to the usage environment, self-cleaning function can be equipped with. It assures the stability of data and reliability of performance; with the built-in self-diagnosis function, it can make sure the accurate data be delivered; besides, the installation and calibration is quite simple.
